Main Specifications
| Diesel Engine Model | YC2115C | YCD3D11C-34 | YCD3D11C-40 | |
| Type of diesel engine | Vertical, in-line, water-cooled, 4-stroke | |||
| Type of cylinder liner | Wet | |||
| Type of combustion chamber | Direct-injection | |||
| Air intake method | Natural | |||
| Number of cylinders - bore x stroke | 2-115 x 120 | 3-105 x 120 | ||
| 12h rated power / speed (kW / r / min) | 24/1500 | 25/1500 | 30/1500 | |
|
Rated Power / speed/ hour (kW / r / min) |
Main engine | 26.4/1548 | 27.5/1500 | 33/1548 |
| Donkey engine | 26.4/1500 | 27.5/1500 | 33/1500 | |
| (g/ kW / r / min) | ≤ 240 | |||
| Steady Timing Ratio (%) | Main engine ≤ 20 donkey enginer ≤ 5 | |||
| Steady Timing (sec) | ≤ 5 | |||
| Start Method | 24V Electric | |||
| External dimension ( L x W x H) (mm) | 696x692x836 | 1360x685x960 | ||
| Appplicable Reduction Gear Case | 16A 40A | |||
| Applicable scope output connecting size SAE standard | Flywheel housing | 3# | 3# / 4# | |
| Flywheel | 11.5# | 11.5# / 10# | ||
